Can simultaneously display two measurements ie 0-10A current and Voltage 0-100v, large, bright and clearly equipped with frame , Just make a square hole hole and insert the frame from the outside, so the result can be neat and elegant.
Technical Parameters:
- Voltage measuring range: 0.0V-100V
- Current test range: 0-10A
- Power range: DC4-30.0V (The maximum input voltage can not exceed 30V.Otherwise the meter will be burned)
- Working current: <20mA
- Refresh rate: 300mS
- Voltage resolution(V):0.1V
- Current resolution(A):0.01A
- Measure accuracy:1%(±1 digit)
- Display method: Double three 0.28 “LED digital tube
- Material:ABS
- Display Colors: RED + BLUE
- Lead Length: 12cm
- Operating temperature: -10 C ~ 65 C
- Equipped with potential CALIBRATION behind the PCB
- DIY Supplies:Electrical
